میکروسکوپ فلورسنت مدل ( B-383FL )
میکروسکوپ فلورسنت مدل ( B-383FL ) کمپانیOPTIKA
Nosepiece : Quintuple revolving nosepiece, rotation on ball bearings
Eyepieces: WF10x/20 mm, high eye-point and secured by screw
Head : Trinocular (fixed 50/50), 30° inclined, 360° rotating.
Observation mode: Brightfield, HBO fluorescence
Specimen stage: Double layer rackless mechanical stage, 233×147 mm, 78×54 mm X-Y range.
Focusing: Coaxial coarse (adjustable tension) and fine focusing mechanism with limit stop to prevent the contact between objective and specimen
Condenser: Abbe N.A. 1.25, with objective-coded iris diaphragm, focusable and centerable.
Transmitted illumination (Fixed Koehler type): X-LED3 with white 3.6 W LED (6,300K) with brightness control. Multi-plug 100-240Vac/6Vdc external power supply.
